Katalog proizvoda

Kontrola statičkog elektriciteta

Tehnička stanica New icon

  • Vidite to u pokretu

    Vidi više

  • Knjižnice
  • Uvid u nove proizvode
  • Malo inspiracije

Kategorije

Štapni ionizatori

Štapni ionizatori
IZT44/45
NOVO

IZT44/45

  • Bar + high voltage power supply + controller
  • Pulse AC type, high density emitter arrangement
  • Powerful static elimination is possible with no air supply
  • Compact bar: Height 23 mm x Width 20 mm
  • One controller can control a maximum of 8 ionizers
  • Up to 4 high voltage power supply modules can be connected to one controller
  • Multiple alarms & functions.

IZS40/41/42, Bar Type Ionizer

IZS40/41/42, Bar Type Ionizer

  • IZS40: Basic type (AC, DC) / IZS41: High speed (AC, Sensing AC, DC) / IZS42: Dual AC type.
  • Controller integrated in the bar.
  • Autobalance sensor, feedback sensor.
  • Wireless remote control.
  • Transition wiring for ionizers serial connection.
  • Display and warning alarms.

IZS31, Bar Type Ionizer w/Feedback or Autobalance Sensor

IZS31, Bar Type Ionizer w/Feedback or Autobalance Sensor

  • Bar lengths from 300 - 2300mm
  • Needle material: tungsten, silicon, or stainless steel
  • NPN or PNP output
  • Optional sensors
  • Various made-to-order options

IZT40/41/42

IZT40/41/42

  • Separate controller bar type ionizer
  • Potential amplitude: As low as 25 V or less
  • Rapid neutralisation of static electricity: As fast as 0.1 s.
  • Compact: Height 37 mm x Width 30 mm
  • One controller can control a maximum of 4 ionizers
  • Monitor and operate bars which are installed in an inaccessible location
  • Multiple alarms & functions.

Mlazni ionizatori

Mlazni ionizatori
IZN10E, Ionizer, Nozzle Type

IZN10E, Ionizer, Nozzle Type

  • Ion balance to +/-10v (range dependent)
  • Operates from 24VDC, with internal high voltage power supply for ion generation
  • Available manifold and bracket mounting styles
  • Electrode needle contamination detector built in
  • Available diffusion nozzles, or straight or bendable bar nozzles
  • Meets CE, UL, CSA and RoHS standards

IZT43, Nozzle Type Ionizer, Separate Controller

IZT43, Nozzle Type Ionizer, Separate Controller

  • Separate controller nozzle-type ionizer
  • IO-Link compatible
  • Compact: Height 32 mm x Width 16 mm
  • IZTC41 controller can control a maximum of 4 ionizers
  • Monitor and operate nozzles which are installed in an inaccessible location
  • Multiple alarms & functions
  • Static elimination with no air supply.

Gun Ionizer

Gun Ionizer
IZG10, Gun Type Ionizer

IZG10, Gun Type Ionizer
Ventilatorski ionizatori

Ventilatorski ionizatori
IZF10, Ionizer, Fan Type

IZF10, Ionizer, Fan Type

  • Air flow adjustment function added.
  • Signal output for emitter contamination detection function added.
  • Slim design.
  • Offset voltaje (Ion balance): ±13 V.
  • Rapid static neutralisation: 1.3 seconds.

IZF21/31, Fan Type Ionizer

IZF21/31, Fan Type Ionizer

  • Slim design.
  • Offset voltage (Ion balance): ±5 V.
  • Rapid static neutralization: 0.5 seconds.
  • Flow Rate Adjustment Function.
  • Filter.

Elektrostatička kutija za uklanjanje prašine

Elektrostatička kutija za uklanjanje prašine
ZVB

ZVB

  • Integration of three processes - static neutralisation, dust removal and dust collection - in a single box thanks to a structure that separates ion blow and air blow.
  • Efficient static neutralisation with a diffusion-type nozzle.
  • Dust removal with dedicated nozzles for the air blow.
  • Dust collection with a maintenance-free pneumatic dust collector.
  • Use of emitters that are easy to remove, replace and clean.
  • Optional photoelectric sensor reflecting plate for automatic workpiece detection.

Senzori

Senzori
IZH10, Handheld Electrostatic Meter

IZH10, Handheld Electrostatic Meter

  • Rated charge amount range: ±20.0kV.
  • Minimum display unit: 0.1kV (±1.0 to ±20.0 kV)/0.01kV (0 to ±0.99 kV).
  • Compact & Lightweight: 85g.
  • Backlight for reading in the dark.

IZD10, Electrostatic Sensor

IZD10, Electrostatic Sensor

  • A sensor (based upon the feedback sensor from series IZS31) that detects the electric charge of a work piece and then outputs an analogue voltage.
  • Two models with different potential measurement ranges.
  • 1 to 5 VDC analogue output voltage.
  • Compact dimensions and easy to mount.

IZE11, Electrostatic Sensor Monitor

IZE11, Electrostatic Sensor Monitor

  • Electrostatic Sensor Monitor.
  • A monitor (based upon the similar sized series PSE300) that processes the analogue output of the electrostatic sensor into a digital display.
  • Programmable two colour display.
  • Four different types of output configuration are selectable when ordering.
  • Supports both types of sensors.
  • Compact dimensions and mounting.
  • Wide range of programmable functions.

Cijevi i priključci

Cijevi i priključci
Fittings

Fittings
Tubing

Tubing
Nema rezultata koji odgovaraju vašim kriterijima pretraživanja
